» DVM Test Report: Transient|LineDropout|HL_Nominal|F_Low|1Cycles|100% Load
| Test Details | |
| Schematic | DVM_PFC_Continuous_Conduction_Mode.sxsch |
| Test | Transient|LineDropout|HL_Nominal|F_Low|1Cycles|100% Load |
| Date / Time | 12/10/2015 6:29 PM |
| Report Directory | ac_dc_built_in\Transient\LineDropout\HL_Nominal\F_Low\1Cycles\100%Load |
| Log File | report.txt |
| Screenshot | schematic.png |
| Status | FAIL |
| Simulator | simplis |
| Deck | input.deck |
| Init | input.deck.init |
| Measured Scalar Values | |
| Frequency(Line) | 50 |
| ILine | MIN -1.4557 MAX 8.00358 RMS 889.978m |
| ILine Inrush Current | MAX 8.00358 |
| IPFCOutput | MIN 432.433m MAX 591.107m |
| Overshoot_VPFCOutput | 472.886 |
| VLine | MIN -325.42 MAX 325.178 |
| VLine After Dropout | RMS 230 |
| vout1_recovery_time_2 | 26.115m |
| VPFCOutput | MIN 345.946 |
| VPFCOutput %_diff_last_2_linecycles | 0.00590989% |
| VPFCOutput At Simulation Start Time | AVG 400.083 |
| VPFCOutput During Dropout | MIN 345.946 |
| VPFCOutput Last LineCycle | AVG 400.141 |
| VPFCOutput overshoot | MAX 472.886 |
| VPFCOutput Previous LineCycle | AVG 400.165 |
| VPFCOutput_in_reg | AVG 400.22 MIN 395.407 MAX 405.081 RMS 400.233 PK2PK 9.6734 |
| Measured Spec Values | |
| AC_Settling(PFCOutput) | PASS: Voltage across PFCOutput has settled to (59.0989u) % and is less than or equal to Max Settling Spec of (10m) % |
| Max_ILine_Inrush | PASS: Max. Inrush Current after Dropout for Line (8.00358) is less than or equal to Max. Inrush Spec of (15) |
| Max_VPFCOutput_in_reg | PASS: Max. Output1 Voltage in Reg. (405.081) is less than or equal to Max. Output1 Voltage Spec (420) |
| Min_VPFCOutput_during_Dropout | PASS: Min. Voltage during Dropout for PFCOutput (345.946) is greater then or equal to the Min. Dropout Voltage Spec of (340) |
| Min_VPFCOutput_in_reg | PASS: Min. Output1 Voltage in Reg. (395.407) is greater than or equal to Min. Output1 Voltage Spec (380) |
| Overshoot_VPFCOutput | FAIL: Max. Output1 Voltage (472.886) is not less than or equal to Max. Output1 Voltage Spec (420) |
| Pk2Pk_VPFCOutput_in_reg | PASS: Pk-to-Pk Output1 Voltage in Reg. (9.6734) is less than or equal to Max. Output1 Voltage Spec (10) |
 PFCOutput
VPFCOutput
IPFCOutput
|
|
| SXGPH File | simplis_tran10_235.sxgph |
 Line
VLine
ILine
|
|
| SXGPH File | simplis_tran10_240.sxgph |
| Other SXGPH Files | |
| AC#tran | simplis_tran10_229.sxgph |
